XK7145

Publish time 2020-04-22 16:05

Product information

Features:

With a CNC milling body, this machine boasts strong carrying capacity, it also has three quench hardening guideways, wide guide rail & broad span as well as compact & reasonable structure and overall dimension; spindle are driven by frequency conversion motor via timing belt. The machine has milling, drilling, boring, reaming and etc. multiple functions, which could realize complex & high-precision components’ machining upon plates, boards, shells, molds and etc., it is mainly applied to machine high-precision components, it could process plane & slope, groove, holes and etc. of small and medium-sized components. In overall, this milling machine is an ideal machining equipments for machine, electronics, instruments, meters, molds, molds and etc. industries.

specifications	unit	XK7145
Table size	mm	800x450
Table maximum load	kg	500
T slot(number-width-pitch)		5-18-80
X axis travel	mm	650
Y axis travel	mm	450
Z axis travel	mm	500
Distance between spindlecenter and column surface	mm	485
Distance between spindle nose and worktable surface	mm	130-630
X/Y axis max.rapid traverse	m/min	24
Z axis max.rapid traverse	m/min	18
Cutting feed	mm/min	1-5000
Spindle speed	r/min	80-8000
Spindle taper		BT40
Main motor power	kw	5.5/7.5
X/Y/Z guide rail form		3 axis linear rail
positioning accuracy	mm	0.012/0.01/0.01
Repeat positioning accuracy	mm	0.008/0.006/0.006
Max.tool dia.(adjoin/apart)	mm	80/130 80/125
Max. tool length	mm	300
Max.tool weight	kg	6
Machine dimension	mm	2250x2450x2300
Machine weight	kg	4200
