TCK6340S
    Publish time 2022-03-21 20:54
TCK6340S
Higher accuracy Taiwan linear guideways
Higher speed spindle unit
Higher rigidity cast iron
Spindle servo motor 5.5kw
Integrated automatic lubrication
6 Inch Hollow hydraulic oil station
Specification
Unit
TCK6340S
Max.swing over bed
mm
400
Max.swing over cross slide
mm
180
Max.processing length
mm
400
X/Z axid travel
mm
x:400 z:500
Spindle speed
rpm
4000
Spindle nose

A2-5
Spindle bore
mm
48
Spindle motor
KW
3.7/5.5
Chuck size
in
6/8
X/Z axis feed motor torque
N.m
6/6
X/Z Rapid traverse
m/min
18/18
X/Z axis repeatability
mm
±0.003
Guide form

45 Degree Linear guiderway
Tool post from

gang type tool/Turret post
Cutting tool shape size
mm
20x20
Total power capacity
KVA
9/11
Machine dimension(L*W*H)
mm
2390x1530x1780
Net.weight(about)
kg
2500
Standard configuration:
1) System:GSK980TC3, servo motor and drive.
2) 3-jaw manual chuck.
3) Gang type tool.
4) Lighting system.
5) Cooling system.
6) Automatic lubrication system.

Optional configuration:
1). CNC system: GSK, Siemens, Fanuc, KND, etc.
2). Hydraulic chuck, pneumatic chuck .
3). Hydraulic tailstock, pneumatic tailstock.
4). 4/6-station electric tool post, 8- station electric tool post
5). Automatic bar feeder.
