C9365
    Publish time 2022-03-24 21:03
C9365
Application:
♦Applicable for repairing small brake drums/disc of large & medium vehicles.
♦2 electric power feed enables infinitely variable feeding in either direction with high efficiency.
♦Special support enables stability for turning heavy drums;
♦2 faces of brake disc can be turned simultaneously;
Model
Unit
C9335
C9335A
C9365
Processing dia of brake drum
mm
180-350
180-350
350-650
Processing dia of brake disc
mm
180-350
180-350
180-480
Rotating speed of workpiece
r/min
75/130
75/130
30/49/88
Max travel of tool
mm
100
100
256
Feeding capacity
mm/r
0.15
0.16

Motor power
kw
1.1
1.1
1.1
Overall dimension
mm
695x565x635
695x565x635
1750x800x815
Weight
kg
200
200
480
