Main Specifications

3M9816

Processing Diameter mm

45-160

Max Honing Depth mm

320

Spindle Speed r/min

125,250

Reciprocationg Speed of Honing Head m/min

0-10

Motor Power kw

1.1 / 1.1

Overall Dimensions mm

1240 x 850 x 2310

Packing Dimensions mm

1310 x 1010 x 2100

N.W/G.W kg

940 / 1130
